Circuit breaker MCCB YON MD1250N-MR2 3P 1250А 50kA Ir 0.4…1xIn Isd 1.5…10xIn
Code:
MD1250N-MR2
Circuit breaker MCCB YON MD1250N-MR2 3P 1250А 50kA Ir 0.4…1xIn Isd 1.5…10xIn
Code:
MD1250N-MR2
Rated permanent current Iu, A | 1250 |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz, kA | 50 |
Overload release current setting, A | 500...1250 |
Adjustment range short-term delayed short-circuit release, A | 0.1...0.4 |
Adjustment range undelayed short-circuit release, A | 1.5...10 |
Integrated earth fault protection | Yes |
Type of electrical connection of main circuit | Screw connection |
Device construction | Built-in device fixed built-in technique |
Suitable for DIN rail (top hat rail) mounting | No |
With under voltage release | No |
Number of poles | 3 |
Type of control element | Rocker lever |
Motor drive optional | Yes |
Degree of protection (IP) | IP20 |
DIN rail (top hat rail) mounting optional | No |
Rated current In | 1250 A |
Q'ty of poles | 3 |
Type release | Electronic |
Breaking Capacity Limit Icu | 50 kA |
Regulation of currents in the overload zone | Yes |
Regulation of currents in the short-circuit zone | Yes |
