Current transformer CT50 200/5А, accuracy class -0.5, power - 1ВА
Code: CT50-200-0.5-1
Current transformer CT50 200/5А, accuracy class -0.5, power - 1ВА
Code: CT50-200-0.5-1
| Model | Single-phase current converter |
| Accuracy class | 0.5 |
| Calibrated | Yes |
| Width opening, mm | 50 |
| Height opening, mm | 30 |
| Opening diameter, mm | 40 |
| Number of primary inputs | 1 |
| With copper rail | No |
| Primary rated current, A | 200 |
| Snap mounting | No |
| Secondary connection | Cable |
| Secondary rated apparent power, VA | 1 |
| Secondary rated current, A | 5 |
| Over current limiting factor | FS 5 |
| With shock protection | Yes |
| Marking | CT50-200-0.5-1 |
| Series | YON CT |
| Primary winding current | 200 A |
| Secondary winding current | 0.20833333333333 |
| Accuracy class | 0.5 |
| Hole width | 50 mm |
