current transformer CT60 300/5A, accuracy class - 0.5S-2.300, power - 2.5VA
Code: CT60-300-0.5S-2.5
current transformer CT60 300/5A, accuracy class - 0.5S-2.300, power - 2.5VA
Code: CT60-300-0.5S-2.5
| Model | Single-phase current converter |
| Accuracy class | 0.5 |
| Calibrated | Yes |
| Width opening, mm | 60 |
| Height opening, mm | 50 |
| Opening diameter, mm | 50 |
| Number of primary inputs | 1 |
| With copper rail | No |
| Primary rated current, A | 300 |
| Snap mounting | No |
| Secondary connection | Cable |
| Secondary rated apparent power, VA | 2.5 |
| Secondary rated current, A | 5 |
| Over current limiting factor | FS 5 |
| With shock protection | Yes |
| Marking | CT60-300-0.5S-2.5 |
| Series | YON CT |
| Primary winding current | 300 A |
| Secondary winding current | 0.20833333333333 |
| Accuracy class | 0.5S |
| Hole width | 60 mm |
