current transformer CT60 500/5A, accuracy class - 0.2S-2.500, power - 2.5VA
Code: CT60-500-0.2S-2.5
current transformer CT60 500/5A, accuracy class - 0.2S-2.500, power - 2.5VA
Code: CT60-500-0.2S-2.5
Model | Single-phase current converter |
Accuracy class | 0.2 |
Calibrated | Yes |
Width opening, mm | 60 |
Height opening, mm | 50 |
Opening diameter, mm | 50 |
Number of primary inputs | 1 |
With copper rail | No |
Primary rated current, A | 500 |
Snap mounting | No |
Secondary connection | Cable |
Secondary rated apparent power, VA | 2.5 |
Secondary rated current, A | 5 |
Over current limiting factor | FS 5 |
With shock protection | Yes |
Marking | CT60-500-0.2S-2.5 |
Series | YON CT |
Primary winding current | 500 A |
Secondary winding current | 0.20833333333333 |
Accuracy class | 0.2S |
Hole width | 60 mm |
