Alluminium alloy box two ways M16x1,5, IP55, 118x51x41 mm

Code: 6030-16A

Alluminium alloy box two ways M16x1,5, IP55, 118x51x41 mm

Code: 6030-16A
Mounting method Universal
Colour Grey
Width, mm 51
Depth, mm 42
Length, mm 118
Sealable Yes
Material Aluminium
Number of inlets 2
Cover attachment Screwed
Weatherproof Yes
Degree of protection (IP) IP55
Shape Rectangular
For tube diameter 16 mm
Type of housing feed-through Thread
Equipped with None
Surface protection Untreated
Product type Pull box
Material PVC
Height, mm 118
Width, mm 51
Temperature of mounting, °C -25 ... +70 °С
Ingress Protection rating, IP IP55
Temperature of operation, °C from -25 to +70 °С
Depth, mm 42
Threading M16 x 1,5
