Alluminium alloy box 3 ways M25x1,5, IP55, 118x67x42 mm
Code: 6330-25
Alluminium alloy box 3 ways M25x1,5, IP55, 118x67x42 mm
Code: 6330-25
Mounting method | Universal |
Colour | Grey |
Width, mm | 67 |
Depth, mm | 42 |
Length, mm | 118 |
Sealable | Yes |
Material | Aluminium |
Number of inlets | 3 |
Cover attachment | Screwed |
Weatherproof | Yes |
Degree of protection (IP) | IP55 |
Shape | Rectangular |
For tube diameter | 25 mm |
Type of housing feed-through | Thread |
Equipped with | None |
Surface protection | Untreated |
Product type | Junction boxes |
Material | PVC |
Height, mm | 118 |
Width, mm | 67 |
Temperature of mounting, °C | -25 ... +70 °С |
Ingress Protection rating, IP | IP55 |
Temperature of operation, °C | from -25 to +70 °С |
Depth, mm | 42 |
Threading | M25 x 1,5 |
