IM 25x17 T-form angle (branch), brown (retail)

Code: 00536RB
  • To ask a question
Colour Brown
Width, mm 25
Model Base unit and cover
Halogen free Yes
Depth, mm 17
Surface protection Untreated
Width branch, mm 25
Material quality Polyvinyl chloride (PVC)
Material Plastic
Mounting method cover Inner lying
Number of covers 1
Mounting perforation in bottom Yes
With cable fixing clip Yes
With duct connector Yes
With protection film Yes
Symmetric Yes
Temperature of mounting, °C ­5°С ... +60°С
Width (nominal), mm 25
Ingress Protection rating, IP IP40
Temperature of operation, °C ­5°С ... +60°С
Temperature of operation, °C +60°C
Climate version UHL4
Q'ty of bays 1
Height (nominal), mm 17
Q'ty of holes 3
Fire protection It is not subject to obligatory confirmation of compliance of the requirements of the Federal law №123-ФЗ 22.06.2012
Product type T-branch
