APM Flat L-form angle 20х10 mm, brown

Code: 00407B

APM Flat L-form angle 20х10 mm, brown

Code: 00407B
Colour Brown
Width, mm 22
Model Other
Halogen free Yes
Depth, mm 10
Surface protection Other
Material quality Other
Material Plastic
Mounting method cover Inner lying
Number of covers 1
Mounting perforation in bottom Yes
With cable fixing clip No
With duct connector No
Direction Rising/descending
With protection film No
Symmetric Yes
Angle, ° 90
Temperature of mounting, °C ­5°С ... +60°С
Width (nominal), mm 22
Ingress Protection rating, IP IP40
Temperature of operation, °C ­5°С ... +60°С
Temperature of operation, °C +60°C
Climate version UHL4
Q'ty of bays 1
Height (nominal), mm 10
Q'ty of holes 2
Fire protection It is not subject to obligatory confirmation of compliance of the requirements of the Federal law №123-ФЗ 22.06.2012
Product type Flat angle
