Internal vertical angle 90° 50x400, R300, included with fasteners (joint plates GTO, screws, nuts)
| Colour | Light grey |
| Deflection (angle) | 90° |
| Material | Steel |
| Inner radius, mm | 300 |
| Cable tray width, mm | 400 |
| Cable tray height, mm | 50 |
| Change of direction | Vertically rising |
| Model | Included connector |
| Surface protection | Sendzimir galvanized |
| Material quality | Steel |
| Type of accessories | 90º vertical inner bend |
| Product type | System accessories |
| Height | 50 mm |
| Width | 400 mm |
| Material | Pre-galvanized steel |
