| Width, mm | 440 |
| Height, mm | 88 |
| Depth, mm | 622 |
| Weight, kg | 17 |
| Construction type | 482.6 mm (19 inch) device |
| Input voltage, V | 304...478 |
| USV- technology | Online |
| Standard for interfaces | RS-232 |
| Built-in battery | No |
| Output apparent power, VA | 10000 |
| Output effective power, W | 10000 |
| Phase | Three-Phase/Single-phase |
| Modifications of Output sockets | Terminals |
| Parallel mode | max. 4 |
| Cold start | Yes |
| Auto-restart | Yes |
| Interface | EPO, USB, RS-232, AS400, SNMP |
| External Battery | Yes |
| Service Bypass | Yes |
