Current transformer CT165 6000/5А, accuracy class -0.2S, power - 30ВА

Code: CT165-6000-0.2S-30
Current transformer CT165 6000/5А, accuracy class -0.2S, power - 30ВА
Current transformer CT165 6000/5А, accuracy class -0.2S, power - 30ВА

Current transformer CT165 6000/5А, accuracy class -0.2S, power - 30ВА

Code: CT165-6000-0.2S-30
Model Single-phase current converter
Accuracy class 0.2
Calibrated Yes
Width opening, mm 165
Height opening, mm 65
Opening diameter, mm 65
Number of primary inputs 1
With copper rail No
Primary rated current, A 6000
Snap mounting No
Secondary connection Cable
Secondary rated apparent power, VA 30
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT165-6000-0.2S-30
Series YON CT
Primary winding current 6000 A
Secondary winding current 0.20833333333333
Accuracy class 0.2S
Hole width 165 mm
