Current transformer CT30 200/5А, accuracy class -0.2, power - 1.5ВА

Code: CT30-200-0.2-1.5
Current transformer CT30 200/5А, accuracy class -0.2, power - 1.5ВА
Current transformer CT30 200/5А, accuracy class -0.2, power - 1.5ВА

Current transformer CT30 200/5А, accuracy class -0.2, power - 1.5ВА

Code: CT30-200-0.2-1.5
Model Single-phase current converter
Accuracy class 0.2
Calibrated Yes
Width opening, mm 30
Height opening, mm 30
Opening diameter, mm 30
Number of primary inputs 1
With copper rail No
Primary rated current, A 200
Snap mounting No
Secondary connection Cable
Secondary rated apparent power, VA 1.5
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT30-200-0.2-1.5
Series YON CT
Primary winding current 200 A
Secondary winding current 0.20833333333333
Accuracy class 0.2
Hole width 30 mm
