current transformer CT30 300/5A, accuracy class - 0.300, power - 3VA
Code: CT30-300-0.5-3
current transformer CT30 300/5A, accuracy class - 0.300, power - 3VA
Code: CT30-300-0.5-3
Model | Single-phase current converter |
Accuracy class | 0.5 |
Calibrated | Yes |
Width opening, mm | 30 |
Height opening, mm | 30 |
Opening diameter, mm | 30 |
Number of primary inputs | 1 |
With copper rail | No |
Primary rated current, A | 300 |
Snap mounting | No |
Secondary connection | Cable |
Secondary rated apparent power, VA | 3 |
Secondary rated current, A | 5 |
Over current limiting factor | FS 5 |
With shock protection | Yes |
Primary winding current | 300 A |
Secondary winding current | 0.20833333333333 |
Accuracy class | 0.5 |
Hole width | 30 mm |
