Mounting method Surface mounted (plaster)
Operational temperature, °C -60...60
Material Stainless steel
Explosion-tested version Yes
Degree of protection (IP) IP66
For Ex-zone gas 1, 2
For Ex-Zone dust 21, 22
Impact strength IK07
Cover attachment Screwed
Type of boxes Box, cover mounting on screws
Material Stainless steel AISI 304
Marking Ex e IIC Gb U / Ex tb IIIC Db U
Length 150 mm
Weight 1,61 kg
Temperature range From -60 to + 60 °C
Product type Ex box
Type of protection Ex e, tb
Width 150 mm
Height 120 mm
