Busbar connection BBS-MD63, type PIN, 4 poles, 14 connections, formodular equipment
Code: BBS-MD63P-4P14
Busbar connection BBS-MD63, type PIN, 4 poles, 14 connections, formodular equipment
Code: BBS-MD63P-4P14
| Insulated | Yes |
| Number of phases | 4 |
| Cross section, mm² | 10 |
| Rated permanent current Iu, A | 63 |
| Number of poles | 4 |
| Length, mm | 1000 |
| Conditioned rated short-circuit current Iq, kA | 15 |
| Rated surge voltage, kV | 4 |
| Type of electric connection | Pin |
| Number of modular spacings | 56 |
| Rated short-time withstand current lcw, kA | 15 |
| Suitable for devices with auxiliary switch | No |
| Suitable for devices with N-conductor | No |
| Suitable for number of devices | 56 |
| Max. rated operation voltage Ue, V | 400 |
| Module width, mm | 18 |
