Product type
Type of power supply
Number of digital inputs
Number of digital ouput
Number of analog inputs
Number of analog outputs

Programmable logic controllers (PLC)

Code
Name
C1000-24AT
CPU for programmable logic controller, powered by AC 100-240V, DI 14 DC24V(PNP/NPN), DO 10 DC24V(PNP), communication ports - 2xRS485, 1xEthernet. Support a maximum of 1 BD expansion module and 14 bus expansion modules.
C1000-24DT
CPU for programmable logic controller, powered by DC 24V, DI 14 DC24V(PNP/NPN), DO 10 DC24V(PNP), communication ports - 2xRS485, 1xEthernet. Support a maximum of 1 BD expansion module and 14 bus expansion modules.
C1000-24AR
CPU for programmable logic controller, powered by AC 100-240V, DI 14 DC24V(PNP/NPN), DO 10 Relay, communication ports - 2xRS485, 1xEthernet. Support a maximum of 1 BD expansion module and 14 bus expansion modules.
C1000-24DR
CPU for programmable logic controller, powered by DC 24V, DI 14 DC24V(PNP/NPN), DO 10 Relay, communication ports - 2xRS485, 1xEthernet. Support a maximum of 1 BD expansion module and 14 bus expansion modules.
C1000-02IV
Expansion module, AO 2 (4-20mA/1-5V/0-20mA/0-10V)
C1000-04IV
Expansion module, AI 4 (4-20mA/1-5V/0-20mA/0-10V)
C1000-04RD
Expansion module, RD 4 (Pt100, Pt1000, Cu50, Omh)
C1000-04TC
Expansion module, TC 4, thermocouple cold junction compensation (CJC) options include internal and external compensation. Supported thermocouple types include J, K, E, S, T.
C1000-08DT
Expansion module, DO 8 DC24V(PNP)
C1000-08DX
Expansion module, DI 8 DC24V(PNP/NPN)
C1000-08XR
Expansion module, DO 8 Relay
C1000-16DT
Expansion module, DO 16 DC24V(PNP)
C1000-16DX
Expansion module, DI 16 DC24V(PNP/NPN)
C1000-16XR
Expansion module, DO 16 Relay
C1000-22IV
Expansion module, AI 4, AO 2 (4-20mA/1-5V/0-20mA/0-10V)
C1000-2COM
BD expansion module, communication ports - 1хRS232(PORT0), 1xRS485(PORT3)
C1000-CAN
BD expansion module, communication port - 1хCAN(CANOpen)
C1000-PS
Expansion module, power for bus expansion modules, powered by AC 85-265V, rated output: 5V 1A/24V 250mA
C1000-30AT
CPU for programmable logic controller, powered by AC 100-240V, DI 14 DC24V(PNP/NPN), DO 10 DC24V(PNP), AI 4 IV, AO 2 IV, communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-30DT
CPU for programmable logic controller, powered by DC 24V, DI 14 DC24V(PNP/NPN), DO 10 DC24V(PNP), AI 4 IV, AO 2 IV, communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-40AR
CPU for programmable logic controller, powered by AC 100-240V, DI 24 DC24V(PNP/NPN), 16 Relay, communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-40AT
CPU for programmable logic controller, powered by AC 100-240V, DI 24 DC24V(PNP/NPN), DO 16 DC24V(PNP), communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-40DR
CPU for programmable logic controller, powered by DC 24V, DI 24 DC24V(PNP/NPN), 16 Relay, communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-40DT
CPU for programmable logic controller, powered by DC 24V, DI 24 DC24V(PNP/NPN), DO 16 DC24V(PNP), communication ports - 2xRS485, 1xEthernet. Support a maximum of 2 BD expansion module and 14 bus expansion modules.
C1000-44DR
Expansion module, DI 4 DC24V(PNP/NPN), DO 4 Relay
C1000-44DT
Expansion module, DI 4 DC24V(PNP/NPN), DO 4 DC24V(PNP)
C1000-4DI
BD expansion module, DI 4 DC24V(PNP/NPN)
C1000-4DO
BD expansion module, DO 4 DC24V(PNP)
C1000-88DR
Expansion module, DI 8 DC24V(PNP/NPN), DO 8 Relay
C1000-88DT
Expansion module, DI 8 DC24V(PNP/NPN), DO 8 DC24V(PNP)
