Insulated wire end ferrule for cable cross section 0,25sq.mm, contact length 8mm, violet
Code: 2ART501
Insulated wire end ferrule for cable cross section 0,25sq.mm, contact length 8mm, violet
Code: 2ART501
| Insulated | Yes |
| Surface protection | Tinned |
| Nominal cross section, mm² | 0.25 |
| Material | Copper |
| Colour | Purple |
| Sleeve length, mm | 8 |
| Construction type | Standard |
| For cables resistant to short circuit | Yes |
| Reel/roll packaging | Yes |
| With identification flag | Yes |
| Insulation | Partially isolated |
| Flange shape | Sleeve |
| Product type | Pre-insulated terminals |
| nominal cross section | 0,25 mm² |
| Sleeve type | single |
