Cable trunking for floor 75х17 mm CSP-F, gray
Code:
01332
Cable trunking for floor 75х17 mm CSP-F, gray
Code:
01332
| Colour | Light grey |
| Width, mm | 95.1 |
| Height, mm | 17.5 |
| Self-adhesive | No |
| Length, mm | 2000 |
| Material | Plastic |
| Number of partitions | 1 |
| Sealing lip | No |
| Color | gray |
| Material | PVC |
| Temperature of mounting, °C | +5°С ... +60°С |
| Width (nominal), mm | 75 |
| Ingress Protection rating, IP | IP40 |
| Average filled area, sq.mm | 262+262 |
| Summarized profile area (max), sq.mm | 524 |
| Temperature of operation, °C | +5°С ... +60°С |
| Temperature of operation, °C | +60°C |
| Shock resistance, J | 4 |
| Climate version | UHL4 |
| Q'ty of bays | 2 |
| Voltage of disruption, V | More 2500 |
| Height (nominal), mm | 17 |
| Fire protection | It is not spread combustion (GOST R 53313-2009) |
| Self-glueing base | false |
| Product type | Floor cable ducts |
| Type of groupe | Floor channel |
