Modular wall box for wiring devices VIVA, IP55, 4 modules
Code: 54755
Modular wall box for wiring devices VIVA, IP55, 4 modules
Code: 54755
Colour | Grey |
Width, mm | 142 |
Depth, mm | 63 |
Surface protection | Untreated |
Length, mm | 85 |
Sealable | Yes |
Circuit integrity | None |
Material | Plastic |
Number of inlets | 1 |
Explosion-tested version | Yes |
Cover attachment | Screwed |
With screening | Yes |
Degree of protection (IP) | IP55 |
Inlet from the rear | Yes |
For Ex-zone gas | None |
Tackable | Yes |
For Ex-Zone dust | None |
Shape | Rectangular |
For tube diameter | 20 mm |
Type of housing feed-through | Preembossing |
Equipped with | None |
Color | gray |
Material | ABC-plastic |
Height, mm | 85 |
Width, mm | 142 |
Temperature of mounting, °C | -5°С ... +60°С |
Ingress Protection rating, IP | IP55 |
Temperature of operation, °C | from -25°С to +60°С |
Depth, mm | 55 |
Product type | Wall box |
Number of modules | 4 |
Type of installation | Open installation |
