Outdoor wall-mounted conditioner 500 W, 400 V, 2 ph, 720х300х270 mm

Code: R5KLM05042LO

Outdoor wall-mounted conditioner 500 W, 400 V, 2 ph, 720х300х270 mm

Code: R5KLM05042LO
Width, mm 300
Model Air/air
Height, mm 720
Depth, mm 270
Voltage type AC
With heating function Yes
With temperature control Yes
Function master/slave Yes
Ambient temperature during operating, °C -60...55
Total cooling capacity according to EN 14511 at 35/35 °C, W 500
Speed-regulated Yes
Operating voltage at AC 50 Hz, V 400...400
Operating voltage at AC 60 Hz, V 400...400
Product type Air conditioner
Class of cooling output, W 500
Rated operating voltage V, ~, Hz 400 V, 2 p, 50/60 Hz
Version of cooler Outdoor
Mounting type Wall-mounted
External dimensions of cooler (W x H x D), mm 300 х 720 х 270
Temperature regulating range, ˚C +25…+40
Operating temperature range, ˚C -60…+55
Material Steel sheet
Degree of protection, internal circuit IP55
Degree of protection, external circuit IP34
Weight, kg 27
Refrigeration power DIN 3168 (L35/L35), W 520
Refrigeration power DIN 3168 (L35/L50), W 400
Rated power consumption (L35/L35), kW 0.28
Rated current, A 1,2
Protective device, A 4
Start-up current, A 7
Noise level, dB(A) 67
Coolant type R134a
