No name

Code: EXTRATT80A10

No name

Code: EXTRATT80A10
Width, mm 560
Height, mm 1500
Depth, mm 940
Weight, kg 785
Construction type Free standing model
Input voltage, V 320...460
USV- technology Online
Output effective power, W 80000
SNMP Yes
Number of phases secondary 3
Output power factor 1
Overall efficiency, % 96.5
Efficiency in eco-mode, % 98
Output apparent power, VA 80000
Phase Three-Phase
Modifications of Output sockets Terminals
Parallel mode max. 6
Cold start Yes
Auto-restart Yes
Interface EPO, RS-232, AS400, SNMP, RS-485 (Modbus)
External Battery Yes
Service Bypass Yes
Rated output power 80 kVA
