| Width, mm | 1100 |
| Height, mm | 1400 |
| Depth, mm | 750 |
| Wiring system | DY |
| Degree of protection (IP) | IP00 |
| Built as energy saving transformer | No |
| Rated power, VA | 250 |
| Type of insulation material according to IEC 85 | F |
| Built as safety transformer | No |
| Built as isolating transformer | No |
| Complete device in housing | No |
| Secondary voltage 1, V | 400...400 |
| Primary voltage, kV | 6 |
| Secondary voltage, kV | 0.4 |
| Uk | 0.06 |
| Po | 750 W |
| Pk 120ºC | 3550 W |
| Sound preassure level | 49 dB |
| Option | antivibration mounts |
