No name

Code: TDA06BDYN5AF000
  • To ask a question
Width, mm 1360
Height, mm 1610
Depth, mm 860
Wiring system DY
Degree of protection (IP) IP00
Built as energy saving transformer No
Rated power, VA 630
Type of insulation material according to IEC 85 F
Primary voltage, kV 6
Secondary voltage, kV 0.4
Uk 0.06
Po 1300 W
Pk 120ºC 7300 W
Sound preassure level 55 dB
