No name

Code: TDA16BDYN5AF000
  • To ask a question
Width, mm 1550
Height, mm 2200
Depth, mm 1000
Wiring system DY
Degree of protection (IP) IP00
Built as energy saving transformer No
Rated power, VA 1600
Type of insulation material according to IEC 85 F
Primary voltage, kV 6
Secondary voltage, kV 0.4
Uk 0.06
Po 2350 W
Pk 120ºC 14700 W
Sound preassure level 60 dB
