Code: TDA20BDYN5AF000
Code: TDA20BDYN5AF000
  • To ask a question
Width, mm 1850
Height, mm 2220
Depth, mm 1270
Wiring system DY
Degree of protection (IP) IP00
Built as energy saving transformer No
Rated power, VA 2000
Type of insulation material according to IEC 85 F
Built as safety transformer No
Built as isolating transformer No
Complete device in housing No
Secondary voltage 1, V 400...400
Primary voltage, kV 6
Secondary voltage, kV 0.4
Uk 0.06
Po 3330 W
Pk 120ºC 17900 W
Sound preassure level 60 dB
Option Forced ventilation antivibration mounts
