No name

Code: TDA20BDYN5BF000
  • To ask a question
Width, mm 2500
Height, mm 2550
Depth, mm 1550
Wiring system DY
Degree of protection (IP) IP31
Built as energy saving transformer No
Rated power, VA 2000
Type of insulation material according to IEC 85 F
Primary voltage, kV 6
Secondary voltage, kV 0.4
Uk 0.06
Po 3330 W
Pk 120ºC 17900 W
Sound preassure level 60 dB
