No name

Code: TDA25ADYN5AF000
  • To ask a question
Width, mm 1850
Height, mm 2300
Depth, mm 1270
Wiring system DY
Degree of protection (IP) IP00
Built as energy saving transformer No
Rated power, VA 2500
Type of insulation material according to IEC 85 F
Primary voltage, kV 10
Secondary voltage, kV 0.4
Uk 0.06
Po 3800 W
Pk 120ºC 20500 W
Sound preassure level 65 dB
