No name

Code: TDA32ADYN5AF000
  • To ask a question
Width, mm 2110
Height, mm 2350
Depth, mm 1270
Wiring system DY
Degree of protection (IP) IP00
Built as energy saving transformer No
Rated power, VA 3150
Type of insulation material according to IEC 85 F
Primary voltage, kV 10
Secondary voltage, kV 0.4
Uk 0.08
Po 4700 W
Pk 120ºC 27000 W
Sound preassure level 66 dB
