| Width, mm | 2900 |
| Height, mm | 2650 |
| Depth, mm | 1650 |
| Wiring system | DY |
| Degree of protection (IP) | IP31 |
| Built as energy saving transformer | No |
| Rated power, VA | 3150 |
| Type of insulation material according to IEC 85 | F |
| Primary voltage, kV | 6 |
| Secondary voltage, kV | 0.4 |
| Uk | 0.08 |
| Po | 4700 W |
| Pk 120ºC | 27000 W |
| Sound preassure level | 66 dB |
