Mounting method Surface mounted (plaster)
Material Plastic
Explosion-tested version Yes
Impact strength IK07
Cover attachment Screwed
Degree of protection (IP) IP66
For Ex-zone gas 1, 2
For Ex-Zone dust 21, 22
Nominal cross-section of terminals 2,5 mm2
Terminal type Screw
Quantity 12 шт. x CBC.2 (gray)
Type of a cable gland for: unarmored cable
Series KH
Installation side: A 2 pcs. x outer D: 11,8-18 mm
Material PVC
Product type Explosion-proof box
Electrical equipment group IIC hydrogen
Ex e;t
Geometric dimensions 220x120x90 mm
Installation side: C 1 pc. x outer D: 11,8-18 mm
