No name
Code:
R5SDE228
No name
Code:
R5SDE228
Colour | Grey |
Width, mm | 200 |
Height, mm | 200 |
Depth, mm | 80 |
RAL-number | 7035 |
Material | Steel |
Impact strength | IK10 |
Degree of protection (IP) | IP66 |
Suitable for outdoor set-up | Yes |
Wall fastening possible | Yes |
Surface finishing | Powder coating |
Pole fastening | Yes |
Product type | Terminal box |
Series | SDE |
Material | Steel, light grey, RAL7035 |
Height | 200 mm |
Width | 200 mm |
Depth | 80 mm |
Enclosure design | Screw cover |
Mounting plate | Optional |
Door slats | Not included |
Cable flanges | Not included |
Number of cable flanges | 0 pc |
Enclosure thickness | 1,2 mm |
Door/lid thickness | 1,2 mm |
Gasket | Polyurethane |
Degree of protection | IP66 |
IK | IK10 |
Seismic resistance | Degree 9 of MSK-64 |
Mechanical strength | M39 |
Temperature range | -60...+90 °С |
Climate version | UHL1, OM2, OM3, U3 |
Flammability | G1 |
Russian Maritime Register of Shipping | Yes |
Russian Classification Society | Yes |
